Precision That Drives Power
Built by the best. Delivered by us.
At SABA Drilling, we specialize in sourcing and supplying API-certified Kelly Bushings from trusted global manufacturers. Whether your operation requires square or hexagonal drive types, split-type, roller, or insert bushings, we deliver exactly what your rig demands on time and fully traceable.
🔹 Verified compliance with API Spec 7K
🔹 Fit-for-purpose sizing for 17½” to 49½” rotary tables
🔹 Fast delivery from UAE, China, USA, and more
🔹 Full documentation including MTC & API certs
| Type | Shape | Size Compatibility | Kelly Drive Type | Rotary Table Size | Max Torque (ft-lb) | API Standard | Remarks |
|---|---|---|---|---|---|---|---|
| Square Kelly Bushing | Square (4 or 6 sides) | 3" – 4¼" Square Kellys | Manual or Power Drive | 17½" – 37½" | ~25,000 – 50,000 | API 7K | Common in conventional rigs |
| Hex Kelly Bushing | Hexagonal | 3" – 6" Hex Kellys | Power Drive / Top Drive | 17½" – 37½" | ~30,000 – 60,000 | API 7K | Used with hex Kelly bar |
| Master Bushing Insert | Insert (split) | For use with master bushing | Square / Hex Interchangeable | 27½" – 49½" | N/A (depends on master) | API 7K | Adapter bushing for inserts |
| Roller Kelly Bushing | Square / Hex | 3" – 4¼" | Manual / Hydraulic Rotary | 17½" – 37½" | High | API 7K | Equipped with bearings for smoother rotation |
| Universal Kelly Bushing | Dual-fit (Sq/Hex) | Adjustable for both types | Compatible with multiple | 20½" – 49½" | Mid-range | API 7K | For versatile drilling applications |
Kelly Bushings & Drives Precision Engineered, API Certified
At SABA Drilling, we supply a full range of Kelly Bushings and Kelly Drives designed to deliver smooth, efficient torque transmission between the rotary table and drill string. Built to API 7K standards, our bushings are manufactured for rugged conditions, high torque, and long operational life.
In stock. Ready to ship. Fully supported.
🔹Square & Hexagonal drives
🔹 Roller-type, Split-type, Master Insert
🔹 Compatible with NC38, NC50, 4″ IF Kellys
🔹 Fits rotary tables from 17½” to 49½”
🔹 API 7K / ISO certified with full traceability
Whether you’re upgrading an existing rotary system or sourcing components for a new rig, we deliver fast, globally, and with the documentation you need.
Built for Torque. Supplied with Precision.
At SABA Drilling, we supply a full range of Kelly Bushings designed to deliver smooth, efficient torque transmission between the rotary table and the Kelly drive. Engineered by trusted manufacturers and certified under API Spec 7K, these components are the critical link between power and motion.
🔹Available in square and hexagonal configurations
🔹 Compatible with rotary tables from 17½” to 49½”
🔹 Roller-type and split-type options
🔹 In-stock and ready for immediate delivery
🔹 Supplied with full MTC & documentation
Whether you’re upgrading your rig or replacing worn bushings, we’ll get you the part you need—fast, verified, and globally shipped.
